| Place of Origin: | Qingdao, China |
|---|---|
| Brand Name: | DEERMA |
| Price: | $2,000.00/sets >=1 sets |
| Packaging Details: | Outside package:Stretch film |
| Supply Ability: | 20 Set/Sets per Month |
| Condition: | New | Plastic Type: | PVC PP PE WPC |
|---|---|---|---|
| Machine Type: | Plastic Crusher | Max.Production Capacity (kg/h): | 400 |
| Production Capacity (kg/h): | 300 - 400 Kg/h | Use: | Pipe Crusher |
| Voltage: | 380V/50Hz/3Phase | Dimension(L*W*H): | 2700*1350 *2200 |
| Power (kW): | 11 | Weight (T): | 1580 |
| Warranty: | 1 YEAR | Applicable Industries: | Manufacturing Plant, Construction Works |
| Key Selling Points: | Competitive Price | Showroom Location: | None |
| Machinery Test Report: | Not Available | Video Outgoing-inspection: | Provided |
| Warranty Of Core Components: | 1 Year | Core Components: | Motor |
| Crusher: | SWP 360 PP / PE / PVC Plastic Crusher Machine | Capacity: | 400kg/h |
| Motor: | 11kw | Final Product: | Small Plastic Crap |
| Blades Material: | SKD-11 | Power Supply: | 380V 50H 3PHASE |
| Color: | Customized | Crush Chamber: | 500*500*300MM |
| Marketing Type: | Ordinary Product | Port: | Qingdao |
This crusher/crushing machine is used in crushing waste plastics and defective plastic products to plastic granules.it mainly used for crushing the plastic PVC,PP,PE,HDPE, LDPE pipes, window and door profile, various plastic sheet and so on. We have different kinds of crusher, you can choose the suitable according to your material.
Feature:
1-Steel body and clamping blade prevent the machine from cracking
2- Stepped blades increase shearing strength and crushing efficiency
3-Movable screen is easily to assembly, disassemble and wash
4-Sound separation layer in the feeding door lowers operations noise levels
SWP/PC model PVC Pipe Grinder/ Plastic Profile Crusher:
1) Suitable for recycle of all kinds of plastic bottles, containers, pellicle, plastics sheets,spurs from injection molding machines and extrustion parts.
2) The cutter stand is designed as a step-shearing style, which can resolve the force bored by cutting, and increase the force of cutting greatly.
| Model | SWP160 | SWP200 | SWP260 | SWP360 | SWP400 | SWP560 |
| Rotating diameter (mm) | 160 | 200 | 260 | 360 | 400 | 560 |
| Rotating knives | 8 | 3 | 3 | 3 | 5 | 6 |
| Rotating speed (r/min) | 500 | 870 | 580 | 536 | 500 | 500 |
| Fixed knives | 2 | 2 | 2 | 2 | 2 | 4 |
| Mesh size (mm) | 8 | 8 | 10 | 10 | 10 | 10 |
| Crushing capacity (kg/h) | 60-120 | 50-110 | 150-300 | 300-400 | 350-450 | 400-650 |
| Motor power (KW) | 3 | 5 | 7.5 | 11 | 15 | 30 |
| Feeding size(mm) | 220*100 | 240*350 | 330*220 | 520*270 | 330*260*2 | 460*520*2 |
| Weight (kg) | 305 | 450 | 750 | 800 | 980 | 980 |
