| Place of Origin: | Shandong, China |
|---|---|
| Brand Name: | Deerma |
| Certification: | ISO9001:2008 /CE |
| Price: | $25,000.00/sets >=1 sets |
| Applicable Industries: | Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Restaurant, Food Shop, Construction Works | Showroom Location: | Egypt, Peru, India, Russia, Thailand, Kenya, South Korea, Romania, South Africa |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
| Core Components: | Bearing, Gearbox, Motor, Pump | Condition: | New |
| Type: | Pipe Production Line, Pipe Production Line | Pipe Material: | PE, PE |
| Application: | Water Pipe & Gas Pipe | Production Capacity: | 4-12 M / Min |
| Voltage: | 380V | Power: | Install Power 80kw |
| Dimension(L*W*H): | 25 X 2.2 X 3.0m | Weight: | 8000 Kg |
| Warranty: | 1 Year | Key Selling Points: | Easy To Operate |
| Output Capacity: | 80-120kg/h | Tractor Speed: | 4-12m/min |
| Drive Motor: | SIEMENS Motor | Reduction Gearbox: | Deerma |
| Temperature Controller: | OMRON Controller | Inverter: | ABB Invereter |
| Guarantee: | 12 Month |
| Item | SJ65/33 | SJ75/30 | SJ90/30 |
| Max Dia. Of pipe(mm) | 16-63MM | 20-110MM | 50-160MM |
| Main machine | SJ65/30+SJ25/25 | SJ75/30+SJ25/25 | SJ90/30+SJ25/25 |
| Motor power(kw) | 37KW | 37KW | 55KW |
| Max. capacity(kg/h) | 50-120KG/G | 70-140KG/H | 80-160KG/H |
| Traction speed(m/min) | 0-12M/MIN | 0-8M/MIN | 0-8M/MIN |
| length(mm) | 25000 | 34000 | 44000 |
SJ65/33 PE Pipe Machine ( 16-63mm )
SJ 90/33 PE Pipe Machine (75-160mm)
SJ75/30 PE Three-Layer Pipe Co-extrusion Machine
A: Deerma Company is an industry manufacture of Extrusion Machines.
Q:All of your products are made by your self or compacted via purchasing the others?
A: we have independent technical team who focus on design & development & Manufacture extrusion machines. all the products are made by our technical team.
Q:Annual Production Capacity( Previous Year)
A: About 80 lines from 2014.1 to 2014.12 and total revenue is about USD 2500000
Q: Is there quality control on all production lines?
Yes, all production lines have adequate quality control
Q:Do the QA/QC inspectors work independently from the production line? Yes
Q:How many QA/QC inspectors in total? 4
Machine running videos:
PVC PIPE MACHINE
https://youtu.be/pCeps-t7PKw
https://youtu.be/JA8NzV8rbQU
PVC DOUBLE PIPE MACHINE
https://youtu.be/08PNQjRHKQI
HDPE PPR PIPE MACHINE
https://youtu.be/M4sSyTfsxY0
PVC GARDEN HOSE MACHINE
https://youtu.be/kKAM44Kyt2Q
PP/PE/PVC SINGLE WALL CORRUGATED PIPE MACHINE
https://youtu.be/09tMsWALXT8
PVC MARBLE BOARD MACHINE
https://youtu.be/Ie1Wckb8biU
PVC MARBLE FRAME MACHINE
https://youtu.be/Cu4uob5iHUg
WPC PE PROFILE MACHINE
https://youtu.be/a6UG_G8qmKA
PVC CORNER BEAD MACHINE
https://youtu.be/IUdGm-iW7QY
PVC CEILING MACHINE
https://youtu.be/VvEBQzcooWY
PVC HOLLOW DOOR MACHINE
https://youtu.be/7U8szgnP22M
PVC HOLLOW WALL CORRUGATED SHEET MACHINE
https://youtu.be/U-Ue40rcp_Q
PVC FOAM BOARD MACHINE
https://youtu.be/Ic04ciIcFTg
PVC COIL MAT MACHINE
https://youtu.be/mnRy6nXrtgs
